PSDIM350

350mA Driver

PSDIM350

350mA Driver

Product data

Warranty
5 years
Ambient Temperature
-25°C - 50°C
Efficiency
>80%
Connection Input
0.5-2.5mm² max.
Connection Output
0.5-2.5mm² max.
Driver Output Voltage
2-74V
Driver Output Current
350mA
Protection
Short circuit, overload & overheating
Power Factor
0.95
Product Input Current
0.25A

About the PSDIM350

A 25W constant current LED driver for 350mA Collingwood LED products. Fit up to 18 1W or 6 3W 350mA LED products, which is also compatible with Collingwood’s range of recessed LED retail lights. Fit up to two RDSS or SQSS products. The PSDIM350 can be controlled by a 1-10v analogue dimmer if you wish to dim. Link up to ten PSDIM350 to one 1-10v dimmer by using a 1m sync cable provided. An extended sync cable of 4m is also available as a separate product to further extend the distance between each power supply.

Features & Benefits

1-10V dimmable

IP20 rated

350mA
