PSDAL20024

24V Driver

PSDAL20024

PSDAL20024

24V Driver

Product code: PSDAL20024
Spec sheet IES File LDT File Flyer Product care

Product data

Warranty
3 Years
IP Rating
IP66
Ambient Temperature
-25°C - 50°C
Efficiency
85
Connection Input
Mains: 0.25m, 1mm² 3-core cable Ø: 7.5mm DALI: 0.25m, 0.75mm² 2-core cable Ø: 7mm
Connection Output
0.25m, 1.5mm² 2-core cable Ø 9mm
Driver Output Voltage
24
Driver Output Current
8.33A max.
Protection
Short circuit, overload & overheating
Power Factor
0.98
Product Input Current
1.4
Input
220-240V AC

About the PSDAL20024

DALI dimmable 24V LED driver, IP66 for indoor and outdoor environments

Features & Benefits

200W max output

IP66 rated

DALI dimmable
