The Arc wallpack has been produced to light the external perimeter of a building. When mounted at 3 metres height and spaced 8 metres apart, the Arc shall illuminate a pedestrian walkway to >5lux with a comfortable uniformity and reduced upward light glow. Designed to be an attractive wall mounted feature, it also has a photocell which shall automatically switch the light ON at dusk and OFF at dawn. A colour switch is also included to allow you to decide temperature suits your brickwork best and emergency versions are available as part of the range. The Arc wallpack in available in modern Anthracite Grey (RAL7016).
| Code | Adjustability | Beam Angle | Body Material | CCT Range | Colour / Finish | Dimmable Option | Emergency Option | IP Rating | Length | Lumens Range | Mounting Type | Sensor Option | Wattage Range | Width | Downloads |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ARA1N | Not adjustable | 98 | ADC12 Aluminium Alloy | 3000K / 4000K / 5000K | Anthracite | None | Optional | IP66 | 293 mm | 1650 | Wall | Photocell | 10W | 97 mm | |
| ARA1NE | Not adjustable | 98 | ADC12 Aluminium Alloy | 3000K / 4000K / 5000K | Anthracite | None | Manual-Test | IP66 | 293 mm | 1650 | Wall | Photocell | 10W | 97 mm |
